Hydraulic Pulverizer
Category：
Crushing/Demolition
2. It has the unique layout design of the jaw teeth×, with double layer wear resistance protection, and is made of imported HARDOX400 sheet mate₽rial.
産品咨詢電(diàn)話(huà)：
086-535-2130397
Hydraulic Pulverizer
Product description
Product Features：
1. It is used for secondary crushing of steel and con≥crete and separation of steel and concrete.
2. It has the unique layout design of the jaw teeth, with doub♥le layer wear resistance protection, and is made of imported H₩ARDOX400 sheet material.
3. The structure is optimized through load design to balance the★ opening size and crushing force.
|
Model |
Unit |
JXC04 |
JXC06 |
JXC08 |
JXC10 |
|
Dead-weight |
kg |
660 |
1350 |
1750 |
2750 |
|
Max Opening |
mm |
577 |
730 |
900 |
1015 |
|
Length |
mm |
1720 |
2000 |
2150 |
2374 |
|
Width |
mm |
658 |
660 |
706 |
860 |
|
Max Crushing Force |
t |
83 |
105 |
165 |
225 |
|
Max Shear Force |
t |
126 |
165 |
210 |
305 |
|
Blade Length |
mm |
120 |
150 |
180 |
200 |
|
Driving Oil Pressure |
Kg/cm² |
230 |
300 |
320 |
380 |
|
Suitable Excavator |
t |
6-12 |
12-18 |
18-26 |
26-30 |
