Quick Hitch Coupler
Product Features:
1. JXM quick hitch coupler is made by high strength₩ manganese steel, with structural integration design an¥d hard-wearing quality. It's applicable to all kinds of tonnage excavato♣r's assembly requirement.
2. The operator's cabin is equipped with an electric switch which is con★venient for the driver's operation. It replaces αthe high cost oil pressure by electric power.
3. Each oil cylinder is equipped with check valve and a mechanical locking safety device to ensure the oil flow, ensuring coupler to regular work when the oil circuit on or ↑cut off.
4. Each quick hitch coupler have installed safety pin to protect system, also ensure normal♠ operation when cylinder failure as "dual protect" function.
P Type Quick Hitch Coupler
|
Model |
Unit |
JXK-MINI |
JXK-02 |
JXK-04 |
JXK-06 |
JXK08 |
JXK10 |
JXK17 |
|
Length（C） |
mm |
300-450 |
550-595 |
581-610 |
795-825 |
888-980 |
980-1060 |
1005-1150 |
|
Height（G） |
mm |
246 |
312 |
310 |
388 |
492 |
574 |
558-610 |
|
Width（B） |
mm |
175 |
258-263 |
270-280 |
353-436 |
449-483 |
543-568 |
606-663 |
|
Pins Center Distance（D） |
mm |
80-150 |
230-270 |
290-360 |
380-420 |
460-480 |
473-540 |
550-620 |
|
Arm Width（A) |
mm |
80-140 |
155-170 |
180-200 |
232-315 |
306-340 |
375-411 |
416-469 |
|
Cylinder Stroke（E) |
mm |
95-200 |
200-300 |
300-350 |
340-440 |
420-510 |
460-560 |
600-650 |
|
Vertical Pins Center Distance |
mm |
159 |
200 |
200 |
260 |
325 |
385 |
360 |
|
Weight |
kg |
30 |
60-70 |
80-90 |
220-250 |
400-430 |
500-650 |
700-1000 |
|
Working Pressure |
Kg/cm² |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
|
Necessary Flow |
L/min |
10-20 |
10-20 |
10-20 |
10-20 |
10-20 |
10-20 |
10-20 |
|
Suitable Excavator |
t |
1.5-4 |
4-7 |
5-8 |
9-19 |
17-23 |
23-30 |
33-45 |
H Type Quick Hitch Coupler
|
Model |
Unit |
JXK-06 |
JXK-08 |
JXK-10 |
JXK-17 |
|
Length（C） |
mm |
795-855 |
1060 |
990-1200 |
1000-3000 |
|
Height（G） |
mm |
430 |
492 |
540 |
580 |
|
Width（B） |
mm |
365-420 |
449-483 |
543-568 |
620 |
|
Pins Center Distance（D） |
mm |
370-420 |
460-480 |
473-540 |
550-620 |
|
Arm Width（A) |
mm |
232-315 |
306-340 |
375-411 |
416-469 |
|
Cylinder Stroke（E) |
mm |
340-440 |
420-510 |
460-560 |
600-650 |
|
Vertical Pins Center Distance |
mm |
220 |
275 |
300 |
360 |
|
Weight |
kg |
130-150 |
300-330 |
430-510 |
490-630 |
|
Working Pressure |
Kg/cm² |
200 |
200 |
200 |
200 |
|
Necessary Flow |
L/min |
10-20 |
10-20 |
10-20 |
10-20 |
|
Suitable Excavator |
t |
9-19 |
17-23 |
23-30 |
33-45 |
